Description

The Pacbrake HP10723 Onboard Air Accessory Kit unlocks accessory air functionality from your BRAVO onboard air system. Use it to inflate tires, sport balls, air mattresses and more, or to run pneumatic tools wherever you need air. Everything connects to the onboard air system and packs away in a heavy-duty nylon storage bag.

Part Number: HP10723

Features

• 25 ft coiled air hose with 1/4 in NPT male ends and quick-connect fittings
• 16 ft of 1/4 in OD nylon air line
• Air blow gun with rubber, tapered and safety nozzles plus inflation needles
• Dual-head air chuck and pencil tire gauge
• Full complement of industrial plugs, sockets and push-to-connect fittings
• Heavy-duty nylon storage bag keeps everything in one place

Specifications

• Air hose: 25 ft coiled, 1/4 in NPT
• Nylon air line: 16 ft, 1/4 in OD
• Quick connect: 1/4 in industrial interchange
• Dimensions: 11 in x 8 in x 7 in (L x W x H)

Notes

• Requires an air compressor. A tank is recommended for optimal performance.
• If using with a non-BRAVO system, ensure it is compatible with an added accessory system.
